本文将介绍如何使用spire.xls for java在excel中创建迷你图表，以及编辑和删除表格中的迷你图表。

创建迷你图表

import com.spire.xls.*;
import java.awt.*;
public class createsparklinechart {
    public static void main(string[] args) {
        //创建一个workbook类对象并加载excel文档
        workbook workbook = new workbook();
        workbook.loadfromfile(  "test.xlsx");
        //获取第一个工作表
        worksheet sheet = workbook.getworksheets().get(0);
        //添加折线迷你图，设置折折线迷你图格式
        sparklinegroup sparklinegroup1 = sheet.getsparklinegroups().addgroup();
        sparklinegroup1.setsparklinetype(sparklinetype.line);
        sparklinegroup1.setsparklinecolor(new color(153,50,204));
        sparklinegroup1.setshowhighpoint(true);
        //设置添加折现迷你图表的单元格以及图表生成的数据范围
        sparklinecollection sparklines1 = sparklinegroup1.add();
        sparklines1.add(sheet.getcellrange("b3:f3"), sheet.getcellrange("g3"));
        //添加柱形迷你图，并设置图表颜色
        sparklinegroup sparklinegroup2 = sheet.getsparklinegroups().addgroup();
        sparklinegroup2.setsparklinetype(sparklinetype.column);
        sparklinegroup2.setsparklinecolor(new color(244,164,96));
        sparklinegroup2.setshowhighpoint(true);
        //设置添加柱形迷你图表的单元格以及图表生成的数据范围
        sparklinecollection sparklines2 = sparklinegroup2.add();
        sparklines2.add(sheet.getcellrange("b4:f4"), sheet.getcellrange("g4"));
        //添加盈亏迷你图，并设置颜色
        sparklinegroup sparklinegroup3 = sheet.getsparklinegroups().addgroup();
        sparklinegroup3.setsparklinetype(sparklinetype.stacked);
        sparklinegroup3.setsparklinecolor(new color(255,20,147));
        sparklinegroup3.setshowhighpoint(true);
        //设置盈亏迷你图表的单元格以及图表生成的数据范围
        sparklinecollection sparklines3 = sparklinegroup3.add();
        sparklines3.add(sheet.getcellrange("b5:f5"), sheet.getcellrange("g5"));
        //保存文档
        workbook.savetofile("addsparkline.xlsx", excelversion.version2013);
        workbook.dispose();
    }
}

迷你图表创建效果：

编辑迷你图表

import com.spire.xls.*;
import com.spire.xls.core.spreadsheet.isparklinegroup;
import com.spire.xls.core.spreadsheet.isparklines;
public class modifysparkline {
    public static void main(string[] args) {
        //创建实例，加载文档
        workbook wb = new workbook();
        wb.loadfromfile("addsparkline.xlsx");
        //获取工作表
        worksheet sheet = wb.getworksheets().get(0);
        //修改第2个迷你图组中迷你图表类型和数据范围
        isparklinegroup sparklinegroup = sheet.getsparklinegroups().get(1);
        sparklinegroup.setsparklinetype(sparklinetype.line);
        isparklines sparklines = sparklinegroup.get(1);
        sparklines.refreshranges(sheet.getcellrange("c4:f4"), sheet.getcellrange("g4"));
        //保存文档
        wb.savetofile("modifysparkline.xlsx", excelversion.version2013);
        wb.dispose();
    }
}

迷你图表修改结果：

删除迷你图表

import com.spire.xls.*;
import com.spire.xls.core.spreadsheet.isparklinegroup;
public class clearsparkline {
    public static void main(string[] args) {
        //创建实例，加载文档
        workbook wb = new workbook();
        wb.loadfromfile("addsparkline.xlsx");
        //获取工作表
        worksheet sheet = wb.getworksheets().get(0);
        //获取第三个迷你图表
        isparklinegroup sparklinegroup = sheet.getsparklinegroups().get(2);
        //从工作表中删除图表
        sheet.getsparklinegroups().clear((sparklinegroup) sparklinegroup);
        wb.savetofile("clearsparkline.xlsx",excelversion.version2013);
        wb.dispose();
    }
}

迷你图表删除效果：
