本文介绍如何使用spire.doc for java在word文档中添加各种预定义的图形以及图形组合。

添加图形

import com.spire.doc.document;
import com.spire.doc.fileformat;
import com.spire.doc.section;
import com.spire.doc.documents.*;
import com.spire.doc.fields.shapeobject;
import java.awt.*;
public class insertshapes {
    public static void main(string[] args) throws exception {
        //创建document对象
        document doc = new document();
        //添加section和段落
        section sec = doc.addsection();
        paragraph para = sec.addparagraph();
        //添加矩形
        shapeobject rectangle = para.appendshape(130, 80, shapetype.rectangle);
        rectangle.setfillcolor(color.darkgray);
        rectangle.setstrokecolor(color.darkgray);
        rectangle.setverticalposition(50);
        //添加三角形
        shapeobject triangle = para.appendshape((float)(160/math.sqrt(3)),80, shapetype.triangle);
        triangle.setstrokecolor(color.red);
        triangle.setfillcolor(color.orange);
        triangle.setverticalposition(50);
        triangle.sethorizontalposition(230);
        //添加圆形
        shapeobject circle = para.appendshape(80,80, shapetype.ellipse);
        circle.setfillcolor(color.red);
        circle.setstrokeweight(15);
        circle.setverticalposition(50);
        circle.sethorizontalposition((float)(300   160/math.sqrt(3)));
        //保存文档
        doc.savetofile("insertshapes.docx", fileformat.docx);
    }
}

添加图形组合

import com.spire.doc.document;
import com.spire.doc.fileformat;
import com.spire.doc.section;
import com.spire.doc.documents.paragraph;
import com.spire.doc.documents.shapetype;
import com.spire.doc.fields.shapegroup;
import com.spire.doc.fields.shapeobject;
import java.awt.*;
public class insertshapegroup {
    public static void main(string[] args) {
        //创建document对象
        document doc = new document();
        //添加section和段落
        section sec = doc.addsection();
        paragraph para = sec.addparagraph();
        //获取页面内容区域的宽
        float pagewidth = sec.getpagesetup().getclientwidth();
        //添加图形组合到段落，指定其大小和水平位置
        shapegroup shapegroup = para.appendshapegroup(200, 150);
        shapegroup.sethorizontalposition((pagewidth - 200) / 2);
        //计算缩放比率
        float x = (shapegroup.getwidth() / 1000.0f);
        float y = (shapegroup.getheight() / 1000.0f);
        //创建一个圆形
        shapeobject circle_1 = new shapeobject(doc, shapetype.ellipse);
        circle_1.setwidth(80 / x);
        circle_1.setheight(80 / y);
        circle_1.setfillcolor(new color(176, 196, 222));
        circle_1.setstrokecolor(new color(176, 196, 222));
        circle_1.sethorizontalposition(60 / x);//设置其相对于图形组合的水平位置
        //将圆形添加到图形组合
        shapegroup.getchildobjects().add(circle_1);
        //添加另外两个圆形到图形组合
        shapeobject circle_2 = new shapeobject(doc, shapetype.ellipse);
        circle_2.setwidth(80 / x);
        circle_2.setheight(80 / y);
        circle_2.setfillcolor(new color(0, 128, 128));
        circle_2.setstrokecolor(new color(0, 128, 128));
        circle_2.sethorizontalposition(30 / x);
        circle_2.setverticalposition(50 / y);
        shapegroup.getchildobjects().add(circle_2);
        shapeobject circle_3 = new shapeobject(doc, shapetype.ellipse);
        circle_3.setwidth(80 / x);
        circle_3.setheight(80 / y);
        circle_3.setfillcolor(new color(72, 61, 139));
        circle_3.setstrokecolor(new color(72, 61, 139));
        circle_3.sethorizontalposition(90 / x);
        circle_3.setverticalposition(50 / y);
        shapegroup.getchildobjects().add(circle_3);
        //保存文档
        doc.savetofile("insertshapegroup.docx", fileformat.docx_2010);
    }
}
