spire.presentation for .net 6.1版本支持嵌入zip对象到ppt幻灯片。下面通过c#及vb.net代码展示如何来实现zip对象添加。在ppt中嵌入excel对象可参考这篇文章。

using spire.presentation;
using spire.presentation.drawing;
using system;
using system.drawing;
using system.io;
namespace insertzip
{
    class program
    {
        static void main(string[] args)
        {
            //创建一个ppt文档，并获取第一张幻灯片（创建的ppt默认包含一张空白幻灯片）
            presentation ppt = new presentation();
            islide slide = ppt.slides[0];
            //读取zip文件到byte数组
            byte[] data = file.readallbytes("sample.zip");
            //在幻灯片中绘制形状，并添加zip文件对象
            rectangle rec = new rectangle(120, 120, 100, 100);
            ioleobject ole = slide.shapes.appendoleobject("sample.zip", data, rec);
            ole.progid = "package";
            //设置对象封面图片
            image image = image.fromfile("logo.png");
            iimagedata oleimage = ppt.images.append(image);
            ole.substituteimagepicturefillformat.picture.embedimage = oleimage;
            //保存文档
            ppt.savetofile("insertzip.pptx", spire.presentation.fileformat.pptx2013);
            system.diagnostics.process.start("insertzip.pptx");
        }
    }
}

imports spire.presentation
imports spire.presentation.drawing
imports system.drawing
imports system.io
namespace insertzip
	class program
		private shared sub main(args as string())
			'创建一个ppt文档，并获取第一张幻灯片（创建的ppt默认包含一张空白幻灯片）
			dim ppt as new presentation()
			dim slide as islide = ppt.slides(0)
			'读取zip文件到byte数组
			dim data as byte() = file.readallbytes("sample.zip")
			'在幻灯片中绘制形状，并添加zip文件对象
			dim rec as new rectangle(120, 120, 100, 100)
			dim ole as ioleobject = slide.shapes.appendoleobject("sample.zip", data, rec)
			ole.progid = "package"
			'设置对象封面图片
			dim image__1 as image = image.fromfile("logo.png")
			dim oleimage as iimagedata = ppt.images.append(image__1)
			ole.substituteimagepicturefillformat.picture.embedimage = oleimage
			'保存文档
			ppt.savetofile("insertzip.pptx", spire.presentation.fileformat.pptx2013)
			system.diagnostics.process.start("insertzip.pptx")
		end sub
	end class
end namespace

嵌入效果：
